Customized lifting column
B13
3 sections / 12.000 N
The B13 lifting column is a 3-section column that is developed to lift heavy offset loads. The rectangular shape and the larger size make the B13 suitable for demanding applications. With its stiff aluminium tubes and long-life pads, the B13 lifting column offers a stable and reliable guiding system that is maintenance free. Datasheets 2.000 N, 5.000 N and 10.000 N shows our B13-lifting columns for standard applications, and 12.000 N for demanding applications.
Features
- Push
- Built in hall sensors
- Limit switch
Options
Application
- Medical
- Ergonomical
- Industrial
Technical data
B-series B13
| Force, max | 12.000 N |
| Speed | 7 to 125 mm/s |
| Offset load @ 1m | 2.500 Nm |
| Stroke | 50 to 3.000 mm |
| Retracted length | SB: R = S + 60 mm DB: R = S/2 + 200 mm |
| Duty cycle | 2 min ON / 8 min OFF |
| Voltage | 24 V DC |
| Ambient temperature | +10 to +40 °C |
| Current | 8 A |
| Dimensions | 219 mm × 157 mm |
Accessories
Control boxes
Our high-performance control boxes control the lifting columns and can be used for synchronic drive of several columns.
Controllers
There are several kinds of controllers that enables easy and comfortable usage of the columns.
Battery pack
A battery pack is useful in applications when the product needs to be movable. The battery pack includes a 30 Ah battery and a protection case.
Cables
A large selection of cables is offered to fit the variety of control boxes, battery packages and controls.
